100-hole coal-based honeycomb carbon

The 100-hole coal-based honeycomb carbon is manufactured from powdered activated carbon and binding agents and is suitable for this application.

1.Production Process: Base carbon pulverization, mixing, extrusion molding, drying, calcination or activation, cutting, dedusting, and quality inspection.

2.Product Features: Open-channel structure with low pressure drop, modular loading, and suitability for high-airflow systems.

3.Product Functions: Used for VOCs and odor control in high-airflow exhaust systems in painting, printing, electronics, and chemical processing facilities.

4.Main Series: Coal-Based Honeycomb Activated Carbon, available in 100-cell, 625-cell, 1600-cell, and other configurations, with standard and water-resistant versions. The iodine value or benzene adsorption performance is determined according to the specific exhaust gas composition. Suitable for VOCs and odor control in high-airflow exhaust systems in painting, printing, electronics, and chemical processing facilities.

5.Product Dimensions: The standard size is 100×100×100 mm. Other available sizes include 100×100×50 mm and 50×50×100 mm. Custom dimensions are also available upon request.

6.Customization Services: Dimensions, cell count, water resistance, compressive strength, iodine value, and benzene adsorption performance can be customized according to customer requirements.

7.Management Certifications: ISO 9001, ISO 14001, and ISO 45001.

8.Drinking Water Qualification: Coal-based granular activated carbon for water purification has obtained a drinking water hygiene and safety permit from Shanxi Province, China.

9.Technical Patents: Activated Carbon Purification Equipment for Water Treatment; Patent No.: ZL 2023 2 1056124.2.

10.Scientific & Technical Awards: Team members have received the Grand Prize for Scientific and Technological Progress under the Ministry of Education's Outstanding Scientific Research Achievement Awards for Higher Education Institutions, as well as the Second Prize for Scientific and Technological Progress from China North Industries Group Corporation (NORINCO Group).

11.Third-Party Audit: Supplier audit conducted by Bureau Veritas.

12.Sample Service: Free samples are available upon request.

13.Product Packaging: Packed in cartons. For the 100×100×100 mm specification, each carton contains 18 pieces. A total of 56 cartons make up 1 cubic meter, containing 1,008 pieces.

Coal-based honeycomb activated carbon is characterized by a large specific surface area, low resistance to airflow, a well-developed microporous structure, high adsorption capacity, and a long service life; it is widely used in air pollution control. The honeycomb activated carbon adsorption method involves bringing waste gas into contact with porous activated carbon—which possesses a large surface area—thereby adsorbing pollutants from the gas and achieving purification. At an airflow velocity of 2 meters per second, the flow resistance is less than 80 Pascals.

Clients may provide a test report for heavy metal content, or send us samples for analysis.

Why Choose Our Honeycomb Carbon Solution

Your generation office merits dependable discuss treatment without breaking the bank. Our item is particularly designed for operations taking care of discuss volumes between 10,000-15,000 m³/h with VOC concentrations underneath 200mg/m³.

You'll advantage from 15% taken a toll reserve funds compared to higher-hole-count choices. The optimized structure keeps up a weight drop underneath 450Pa, which interprets to genuine cash spared on your power bills each month.

The mechanical quality surpasses 90%, guaranteeing your carbon squares won't disintegrate beneath nonstop wind current affect. This strength implies less substitutions and less downtime for your operations.

Technical Specifications at a Glance

Common Technical Specifications

1. Iodine Value: Iodine value refers to the amount of iodine adsorbed by 1 gram of activated carbon from a 0.1 mol/L iodine solution, expressed in milligrams per gram (mg/g). It is commonly used as an important indicator of the adsorption capacity of activated carbon.

2. Specific Surface Area: Specific surface area refers to the total surface area of all particles contained in a unit mass of material.

3. Carbon Tetrachloride Adsorption Value (CTC): CTC is commonly used as an indicator of the adsorption capacity of activated carbon for organic gas molecules.

4. Benzene Adsorption Rate: Benzene adsorption rate is commonly used to evaluate the adsorption capacity of activated carbon for small organic molecules.

Technical Specification Table

Note: Our company can develop and manufacture water-resistant honeycomb activated carbon according to customer requirements.

Perfect Applications for Your Industry

Our 100-hole coal-based honeycomb carbon works exceptionally well in spray painting booths, printing facilities, and commercial building air purification systems.

If you run a coking plant, chemical factory, or printing operation, you know how challenging VOCs treatment can be. Our honeycomb structure provides low air resistance while maintaining strong adsorption capacity for large volumes of low-concentration organic waste gases.

The uniform hole size and consistent wall thickness ensure predictable performance across your entire filtration system. You won't experience the uneven flow patterns that plague lower-quality carbon products.

What Sets Us Apart

We maintain tens of thousands of tons in inventory across our production bases in Shanxi, Ningxia, Fujian, and Xinjiang. With an annual output capacity of 45,000 tons, we can fulfill your order quickly and reliably.

Our ISO 9001, ISO 14001, and ISO 45001 certifications guarantee consistent quality you can depend on. Every batch undergoes rigorous testing before it reaches your facility.

You'll receive comprehensive support including free adsorption tower design consultations, detailed operational manuals, and ongoing maintenance guidance. Our technical team responds within 24 hours to address any questions or concerns.

Practical Benefits for Your Bottom Line

The energy efficiency of our 100-hole coal-based honeycomb carbon means you'll see lower operational costs month after month. The 20% reduction in energy consumption adds up significantly over a year of continuous operation.

Fast shipping guarantees you're never holding up long for basic supplies. Standard orders arrive inside 5-7 days, keeping your generation plan on track.

Our collaborative investigate with teach like Tsinghua College and the Chinese Institute of Sciences implies you're getting defense-grade innovation adjusted for mechanical utilize. This specialized legacy gives you get to to progressed materials without the premium cost tag.

Frequently Asked Questions

What precisely is 100-hole coal-based honeycomb actuated carbon?

It's a specialized enacted carbon item fabricated from high-quality Jurassic anthracite coal. The "100-hole" assignment alludes to the honeycomb structure, which gives an ideal adjust of surface range and wind stream for treating discuss volumes of 10,000-15,000 m³/h with VOC concentrations underneath 200mg/m³.

Which businesses advantage most from this product?

Small to medium-sized splash portray production lines, printing plants, plastic fabricating offices, and commercial buildings requiring indoor discuss filtration discover this arrangement perfect. It's outlined for operations that require solid VOCs treatment without over the top capital investment.

How does this fathom my operational challenges?

You get three key benefits: taken a toll investment funds of 15% compared to premium choices, vitality proficiency through moo weight drop plan, and helpful acquirement with quick 5-7 day conveyance. This combination addresses the most common torment focuses in mechanical discuss treatment.

What's your cinder substance specification?

Our cinder substance is 8% or less for standard applications. If your handle requires lower fiery debris substance, we can customize the definition to meet your particular requirements.

Can you customize the item for extraordinary applications?

Absolutely. We offer full customization of pore structure, surface region, adsorption execution, and stacked components. Whether you require particular compliance with FDA, CE, or REACH benchmarks, our R&D group can create a arrangement custom-made to your needs.

What bolster do you give after purchase?

You'll get specialized preparing, 24/7 building back, a 12-month guarantee, and free substitution for non-human harm. We too give operational direction and upkeep tips to maximize your carbon's benefit life.

Ready to Improve Your Air Treatment System?

Contact our technical team today to discuss your specific requirements. Email us at greta@carbonxinhua.com and we'll respond within 24 hours with a customized 100-hole coal-based honeycomb carbon solution.
